Product Features:

Contact resistance: ＜ 10m Ω

Insulation resistance: ≥ 10M Ω at DC500V
Voltage endurance: AC500V, 1min, leakage current<2mA
Working temperature range: -45 ℃ -105 ℃
Rated current: 10A
Insertion and unplugging times: ≥ 1000 times
Contact (pin socket): brass gold-plated/1.5 1.0mm ²
IP67
UL94V-0 fire rating

   Application areas:

LED industry, smart lighting, plant lights, wall washers, street lights, stage lighting and other fields.
