Product Features:

Nut type docking installation, easy to use, convenient to install, and stable.
Customized for LED street light module products that comply with CSA standards.
Gold plated contacts, with high corrosion resistance and conductivity, have an effective effect on electricity

The temperature rise caused by the flow.
The locking ring, rubber core, and encapsulation are all made of high thermal plasticity PA material,

UV resistance, oil resistance, high temperature resistance, 125 ° C ball pressure test.
● Adopting threaded docking, compression sealing, integrated injection molding, partition and

The card point anti retreat design ensures long-term and reliable waterproofing.
The contact piece adopts solid contact piece, which meets the requirements of national safety regulations
Waterproof rating: IP67/IP68.

   Application areas:

LED industry, ships, underfloor heating, streetlights, aquaculture, lasers, stage lighting, furniture, display screens, etc,

Featuring a compact and threaded designconnectorThe characteristic of high protection level.
